Does fluidic control matter?

In situ liquid experiment featuring Copper deposition

It can be seen that high flow rates (1200 nl/min) promote plating of the electrode. However, when switching to lower flow rate values (50 nl/min) the growth mechanism changes and dendrites appear.
The pressure-based liquid pump, the absence of dead volumes and the defined liquid channel all contribute to a very responsive system that allows to accurately vary experimental conditions within seconds.
